B. Main Features:
1. 75 HP diesel engine, 2 meters cutting width, Auto Transmission, high efficiency.
2.Double axial flow threshing cylinders and adjustable front & rear sieving plates ensure the grain more clean, less breakage and less loss.
3.Big width conveyer groove with innovated cutter bar lifting system can provide a more efficient feeding and a higher lifting level, convenient for working in paddy field and maintenance, and lower noise and vibration.
4.Lower ground pressure, better for passing in paddy field.
5.Extremely strong Chassis; Excellent waterproof suspension wheel system; Easier turning & control with friction disc brake and special heavy-duty gearbox for hydraulic steering combine harvester.
C. Technical Specifications:
|Working Efficiency||0.53 ~ 0.80Ha./H (1.32 ~ 2.00Acre/H)|
|Overall Dimensions (L x W x H)||4700×2300×2700 mm|
|Rated Power||75 HP (55kw) / 2400 rpm|
|Fuel consumption per hectare||≤30 Kg/Ha.|
|Transmission||HST F:3 / R:3|
|Ground Pressure||≤18 Kpa|
|Min. Ground Clearance||240 mm|
|Cutting Width||2000 mm|
|Type of Lifting||Hydraulic|
|Lifting of Reel||Hydraulic|
|Conveyor||Chain rack tooth type|
|Threshing Cylinder||Tangential Flow + Axial Flow, Dual Spike-tooth type|
|Cleaning||Fan (front blowing + rear suction)+Sieving+re-thresher|
|Paddy fill Method||Grain Tank & Bag|
|Grain Tank||1.1 CBM/ (500-550 kg)|
